High Brightness 2.76 inch Circular TFT display 480*480 resolution 1000nits MIPI Interface 40PINS -30~85℃

Part No.: FT-02865

TFT Type: 2.76/2.8 inch round TFT LCD / IPS TFT

Resolution: 480*480 dots

Viewing Direction: All

Interface: MIPI

Driver IC: ST7701ST

Brightness: 1000 cd/m²

Touch Screen: without touch, with CG Cover Lens

Item No :
FT-02865

Inquiry now

categories

How can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Products Details

This 2.76 (2.80) inch round IPS TFT LCD screen has a resolution of 480x480 pixels and can provide full viewing angle. The LCD module uses the controller IC ST7701ST and supports the 30PIN MIPI interface. The operating temperature can reach -30~85℃, and the ultra-high brightness reaches 1000cd/m2.

This 2.76-inch round TFT module does not have a touch screen, but is equipped with a customized 1.8MM thick glass cover.

Product Drawing：

2.76 inch round TFT LCD

Product Specification:

No.	Item	TFT LCD SPECIFICATION
1	Part No.	FT-02865
2	LCD Size	2.76(2.80) inch round TFT LCD Display
3	Resolution (Pixels)	480(RGB) × 480
4	Active Area	70.13×70.13mm
6	Module Outline(TFT Module)	72.73 x 76.13 mm
7	Display Mode	IPS, Normally Black, Transmissive
8	Viewing Direction	ALL
9	Viewing Angle	85/85/85/85 (L/R/U/D)
10	Contrast	1000:1 (Typ.)
11	Luminance	1000 cd/㎡
12	Backlight	6 CHIP LED White，
13	Surface Treatment	Anti-Glare
14	Temperature Range	Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C
15	Touch Screen	Without TP, with Glass Cover Lens

Products Features:

Round Display: The unique round appearance gives the 2.80 inch TFT LCD module more design inspiration and fashion elements.
High resolution: Its 480x480 resolution makes the image details clearer and the colors more saturated, bringing users a more realistic visual experience
MIPI interface: The MIPI interface supports high-speed data transmission, which helps to achieve smooth image and video display and improve the overall performance and reliability of the system.
Full viewing angle: IPS technology provides an ultra-wide viewing angle of nearly 180 degrees, ensuring clear, consistent and undistorted image quality at different angles.
Wide temperature Range: The operating temperature reaches -30℃ to 85℃, ensuring that 2.76 inch round IPS TFT LCD has excellent environmental adaptability and high reliability and stability in harsh environments.
Ultra-high brightness: With a brightness of up to 1000cd/m², it can maintain a clear display even under strong light, suitable for outdoor applications.
Customized CG cover: The glass cover lens protects the surface of the 2.80 inch round TFT LCD screen from scratches and impacts, and the customized cover adds elements such as logos to create a personalized appearance.
Optical bonding: The optical bonding process between the TFT LCD and the cover glass, enhances the overall aesthetics and improves product reliability.

Shengfeng Technology, is a manufacturer of TFT LCD display module, touch screen, CG cover glass, and intelligent touch display solutions. According to specific application scenarios and needs to meet different installation and use requirements, our company can provide professional personalized customization design, including the development of FPC, the development of TP matching, and full assembly shipment.

Applications:

This 2.76 (2.80) inch circular TFT LCD display has a wide range of application prospects in many fields, such as smart home, knob switch, circular display, car central control display, and car instrument display, thanks to its advanced interface technology, ultra-wide viewing angle, wide temperature design, and ultra-high brightness.
