Graphic 128*64 COG module ST7567 FSTN LCD No backlight Energy Saving

This is a medium-sized graphic 128*64 COG module, of COG LCD+FPC. The LCD panel of FSTN Positive Reflective mode, no backlight.

Item No :
FG-12864019
Resolution :
128*64 dot matrix
LCD mode :
FSTN/Positive /Reflective
Driver IC :
ST7567 / COG
Interface :
Parallel
Backlight Color :
No backlight

Inquiry now

categories

How can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Products Details

The Model# FG-12864019 is one of standard graphic COG modules, of 128x64 dot matrix. It is suitable for displaying various information such as characters and graphics. This 128x64 LCD module adopts LCD technology of FSTN positive mode reflective mode, no need backlight. The 12864 COG module structure consists of LCD panel + FPC, with 1.1mm thickness ITO glass, the COG LCD has outline dimensions of 47.0x37.6x2.8mm, and Viewing Area (VA) of 43.4x28.0mm. The 128x64 COG module is built in with driver IC ST7567, supporting 8-bit parallel interface, connected by an 18-PIN FPC.

128*64 LCD Display Module

Display Type	FSTN/positive /Reflective, COG module
Resolution	128*64
Model SIze	47.037.62.80mm
V.A Size	43.4*28.0mm
Dot Size	0.315*0.385mm
Dot Gap	0.015*0.015mm
View Direction	6:00
Backlight	No backlight
Driver IC	ST7567
Interface	Parallel

Drawing:

128*64 LCD Display Module

Features:

FSTN Positive/Reflective Mode: The 12864 COG module requires No backlight displaying content through ambient light reflection, energy-saving and suitable for outdoor use.
Module Structure: LCD + FPC, featuring a compact structure and easy installation.
ITO Glass Thickness: Without backlight, the selected 1.1mm ITO glass make the whole 128x64 COG modulemodule thickness of 2.8mm ensuring durability and stability.
Module Size: The COG LCD has outline dimensions of 47.0x37.6mm, the compact design makes it suitable for various space-constrained applications.
Dot Size Design: The dot size is 0.315x0.385mm,while dot GAP is only 0.015x0.015mm. This large dot, small GAP design not only ensures the clarity of the displayed content but also maximizes the Viewing Area (VA), enhancing the overall display effect.
Driver IC: The ST7567 driver IC is selected, supporting an 8-bit parallel interface and connecting to an 18-PIN FPC, facilitating integration with various control systems.

For any information about this Graphic 128x64 COG Module, or for product customization and procurement inquiries, please feel free to contact us. We look forward to working with you to create even better display solutions.

Application:

The Model# FG-12864019, the standard 12864 COG module is widely used in various portable devices, instrumentation, industrial control, medical equipment, and other fields due to its compact design, high-definition display effect, and energy-saving characteristics without backlight.

Shengfeng Technology, we promise to strictly control product quality, with every process from raw material procurement to finished product delivery undergoing rigorous testing to ensure stable and reliable product performance. Additionally, we provide comprehensive after-sales service to solve any issues you may encounter during use.

Hot Tags : 128*64 COG module 128x64 dot matrix graphic COG module 12864 COG module 128x64 LCD module LCD Display Module Factory
