4.3 inch 480*800 TFT LCD IPS full viewing RGB Interface Wide Temperature

Features:

This is a high-resolution 4.3 inch TFT LCD module with the following features:

• High Resolution (480x800):  This resolution ensures a delicate presentation of images and texts.
• Portrait Mode Structure:  Perfectly suited for portrait applications, offering a unique viewing experience.
• High Contrast Ratio (1500:1):  Enhances image clarity and detail rendering.
• Wide Viewing Angle (80°/80°/80°/80°):  As an IPS LCD, it achieves an 80-degree viewing angle in all four directions (up, down, left, right), significantly improving the user's viewing experience.
• Interface Type:  The 18-bit RGB interface supports richer color gradations, making color transitions more natural.
• Boost Circuit:  The built-in boost circuit in the module simplifies the system integration process, reducing design complexity and cost.
• Touch Screen (G+G):  Combined with a capacitive touch screen design, it enables smoother user operation and enhances the overall interactive experience of the product.
• Ultra-thin Design:  The touch screen solution employs 0.7MM cover glass + 0.7mm sensor glass, resulting in an overall module thickness of only 3.69mm, meeting the demand for thinness and lightness in modern electronic devices.

Customization Service:

We Shengfeng is capable of providing customization based on customers' requirements. Such as the interface definition of the TFT LCD display, the length of the FPC can be customized according to customer needs, and the selection of IC/LCD/backlight/RTP/CTP can also be designed according to customer requests.

Applications:

This portrait mode, high resolution 480*800 4.3 inch TFT LCD module integrates premium features, making it ideally suited for applications that require high-definition displays and exceptional user experiences. Its versatility extends to various industries, including high-end handheld devices, industrial control interfaces, medical equipment displays, and automotive navigation systems.
