Part No.: FT-03510
TFT Type: 3.5 inch TFT LCD Display/TN
Resolution: 320*240 dots
Viewing Direction: 6:00 o'clock
Interface: RGB
Driver IC: HX8238
Luminance: 350 cd/m²
Metal Frame：with metal Frame
Touch Screen: without CTP touch
Item No :
FT-03510Product Details:
FT-03510 is a 3.5 inch TFT display, 240xRGBx320, QVGA with aspect ratio of 4:3 landscape mode. For mechanical detail, this 3.5” TFT model is having module outline dimension of 76.90 x 63.90mm and active area size of 70.08 x 52.56mm. This 3.5 inch TFT LCD display module is featured with brightness up to 350 cd/m2 (typical value), contrast ratio of 500:1 and best view at 6:00 o'clock. This 3.5” TFT module is built-in with HX8238 IC; it supports RGB Interface, connected by 54pin FPC.
Its operating temperature is range from -20℃ to +70℃ and storage temperatures of -30℃ to +80℃, that make this 3.5 inch TFT LCD display adaptable for industrial applications or other fields requiring wide temperature range.
Product Drawing:
Product Specification:
| No. | Item | TFT LCD SPECIFICATION |
| 1 | Part No. | TF-03510 |
| 2 | LCD Size | 3.5 inch TFT LCD Display |
| 3 | Resolution (Pixels) | 320(RGB) × 240, QVGA |
| 4 | Display Mode | TN TFT, Normally White, Transmissive |
| 5 | Active Area | 70.08 x 52.56mm |
| 6 | Module Dimension(TFT+CTP) | 76.90 x 63.90 x 2.90mm |
| 7 | Viewing Direction | 6:00 o'clock |
| 8 | Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) |
| 9 | Contrast | 500:1 (Typ.) |
| 10 | Luminance | 350 cd/㎡ |
| 11 | Backlight | 6 CHIP LED White， |
| 12 | Surface Treatment | Anti-Glare |
| 13 | Temperature Range | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 14 | Touch Screen | Without touch screen |
Different customers or projects might have diverse requirements. The 3.5”TFT model #FT-03510 is our SF tech’s existing standard part. If its current specifications cannot meet the customer's needs, we can provide customized services based on their specific requirements.
The customized service includes:
Modify frame enclosure
Customize backlight’s brightness and lifetime
Adjust interface type conversion and position
Equip with touch screen of CTP or RTP
Equip with and customize design cover glass
Add more functions of hardware and software
If the customer has more ideas about this 3.5 inch TFT Display, please contact us freely.
